Wide range online concentration sensor PS920 data sheet
MODEL | PS920-A | PS920-D |
the range of concentration BRIX | 0.00-92.00% | |
Resolution | Brix: 0.1% Temperature: 0.1℃ | |
Accuracy of measurement | Brix: ± 0.1% Temperature: ±1.0℃ | |
Temperature of measurement | 5-100℃ (Auto temperature compensation range) | |
Environment temperature | 5-40℃ | |
Input power | DC 24V | |
Key material | Body of sensor: SUS 316L Optional material: babbitt metal | |
Signal output | DC4-20mA | RS-232 |
Level of protection | IP67 dust/water prevention | |
Max pressure | <1 MPa | |
Size | Φ99 x 175mm | |
Optional Accessories | contact with us |
1. System Integration measurement and control, don't need secondary instrument, like PLC or DCS, etc, so easy.
2. Whole machine is stainless steel design, more resistant to complex environment, and more than IP67.
3. Used fast adapter, install easily.
4. Auto cleaning function, don't need optional expensive cleaning module.
5. Hyperpure sapphire to obtain optimum optics performance.
6. Integrated automatic temperature compensation.
7. Autodiagnosis, mul-alarm message put out.
8. Online measurement accuracy more than 0.01%
9. Used high resolution physical CCD chip.
10. Customer can set up control parameter; build-in D, control signal can put out as analog quantity and digital quantity.
11. System can realized seamless joint with factory anto control platform, can monitor equipment running in office.
12. Imported core component to guarantee quality
