PHG-2091Pro Online PH ORP Analyzer
PHG-2091Pro
ONLINE PH/ORP ANALYZER
Online pH / ORP analyzer and pH / ORP controllers are one of the most common water quality analysers in use today in water treatment and process plants and yet online pH / ORP analyzer cause continual problems for their operators. What is needed is a stable, reliable, online pH / ORP analyzer for a reasonable cost. That is exactly what you get with the BOQU Instrument.
A pH / ORP analyzer consist of a Online pH or ORP probe, transmitter and process adaption, combined to best suit your pH control needs. In-line pH analyzers from BOQU Instrument provide accurate process pH measurements in a wide range of environments, from ultrapure water to hygienic measurement in a bioreactor to dirty chemical production.
TECHNICAL PARAMETERS
Model | PHG-2091Pro Online pH / ORP Analyzer | |
Measurement | pH/ORP/Temperature | |
Measurement range | -2 ~16 pH,-2000 ~2000 mV,-30 ~130 ℃ | |
| Accuracy | 0.05pH, ±0.2℃ | |
Housing material | ABS Flame retardant : V0 | |
Power | 90 – 260V AC 50/60Hz | |
Consumption | 4W | |
Output | Two ways 4-20mA output | |
| Communication | RS485 Modbus | |
Relay | Two relays,5A/250V AC 5A/30V DC | |
Temperature.Comp | PT1000/NTC10K | |
Protection | IP65 | |
Data logger | 1000times | |
| Dimension | 98.2×98.2×128.3mm | |
| Hole size | 92*92mm | |
Language | English/简体中文 | |
Installation | Panel/Wall/Pipe mounted | |
INTRODUCTION
