TSG-2087S Online TSS Meter
BOQU ONLINE TSS SENSOR
The BOQU Online TSS sensor also called as suspended solid sensor is available with different online TSS meter with great working performance.the sensor range is 0~120 000mg/L,it adopts standard RS485 Modbus RTU to ensure accuracy.auto-clean brush function to save operation cost and long working service time.it can be match with Online TSS Meter as below:online suspended solids analyser,Online total suspended solids meter,Online mlss meter,Online tss meter,Online effluent monitor Online inlet monitor.
Applications :Municipal/industrial wastewater,Primary & secondary clarifiers,Return activated sludge,Wastewater activated sludge,Mixed liquor,Aeration basins,Final effluent,Municipal water,Pulp and paper,Dairy industry,Mining industry,Chemical process
TECHNICAL INDEXES
Product | BOQU Online TSS Sensor | |
Size | Diameter 60mm* Length 256mm | |
Main Materials | Main Body:SUS316L (Ordinary Version), Titanium Alloy (Seawater Version) | |
Waterproof Rate | IP68 | |
Measurement Range | 0.01-20000 mg/L,0.01-45000 mg/L,0.01-120000 mg/L | |
Indication Resolution | Less than ± 5% of the measured value (depending on sludge homogeneity) | |
Pressure Range | ≤0.4Mpa | |
Flow velocity | ≤2.5m/s,8.2ft/s | |
Storage Temperature | -15~65℃ | |
Environment Temperature | 0~45℃ | |
Calibration | Sample Calibration, Slope Calibration | |
Cable Length | Standard 10-Meter Cable, Max Length: 100 Meters | |
Warranty Period | 1 Year | |
High Voltage Baffle | Aviation Connector, Cable Connector | |
External Dimension | ||
TSG-2087S
ONLINE TSS METER
BOQU Digital Online TSS Meter are designed for the precision suspended solid measurement with RS485 Online TSS Sensor.the instrument provides 4-20mA output, RS485 Modbus RTU and 3 relays output(two relays for high and low limit,another is for cleaning set).also integrated datalogger function,user can easy and quickly download suspended solid measurement data by USB interface.
MAIN FEATURES
Product | TSG-2087S Online TSS Meter |
Power Supply | 90 ~260V AC 50/60Hz |
| Protection | IP65 waterproof and dust rate |
Display range | 0~1000.00mg/L, 0~99999.00 mg/L 99.99~120.0 g/L |
Accuracy | ±2% |
Relays | 5A/250V AC, 5A/30V DC |
Current outpu | 4-20mA |
Digital Communication | MODBUS RS485 |
| Hole size | 138*138mm |
Warranty Period | 1 year |
